CVE-2025-13032: Entering and Breaking the Avast Antivirus Sandbox Part 1

Introduction

At SAFA we aim to create space for our researchers to engage in technical projects that can be published and shared. We believe that sharing offensive research techniques and results serves the wider professional community, and can provide much deserved exposure to our researches and strengthens the security posture of the audited products. Since these assignments are limited in scope and time there is a special focus on selecting targets where impactful results can be achieved with moderate effort.

For this specific public research project we decided to focus on the Avast antivirus software as it is a widely deployed solution, easily accessible (freemium program, even premium features are available through a trial) and provides a rich and complex kernel attack surface through custom drivers.

Furthermore, we had no previous experience working on antivirus software so we were also driven by professional curiosity to explore them in more detail. The result of this brief engagement was the discovery of 4 exploitable kernel heap overflow and 2 local system DOS vulnerabilities. CVE-2025-13032 was assigned to these vulnerabilities.

In the rest of this blog we will detail our approach to conduct vulnerability research on the Avast sandbox kernel driver. We will briefly introduce the sandbox and the attack surface and provide a deeper technical description of the found vulnerabilities. In the following post we will explain how we exploited one of the introduced bugs to achieve a local privilege escalation to System user on an up to date Windows 11 system.

Attack Surface Analysis

Antivirus software in general has a wide attack surface, from logic bugs to memory corruptions, with local and remote attack surface. The idea of targeting such defense mechanisms to bypass system security guarantees is deeply explored in the Antivirus Hacker's Handbook (Koret and Bachaalany 2015) where the authors outline multiple attack scenarios, vulnerability types and surfaces.

As this was a limited scope engagement we decided to only audit kernel components with the specific goal of finding local privilege escalation primitives. In order to progress efficiently we aimed to identify and focus on the attack surface that is presumably directly reachable by the user and processes user controlled data. The multitude of

IOCTL

Avast ships and installs many different kernel components. After checking which of these drivers are accessible to the user, based on their respective ACLs, we compiled a list of potential targets:

• aswRvrt

• aswSnx

• aswSP_Handler

• aswSP_Open

• AswVmm

• AvAswIDS_loc2

• AvAswUniv

We manually checked the different devices in order to find the most promising one based on the number of exposed IOCTLs. The initial reverse engineering effort revealed a series of strings that seemed to suggest that these kernel components are shared between various Gendigital AV products (Avast, AVG, Norton and Avira). We did not verify whether this is the case and if the implementation details are the same, however, this could further increase the reach and impact of potential vulnerabilities.

After this cursory analysis our choice of target became the

aswSnx

IRP_MJ_DEVICE_CONTROL

IRP_MJ_DEVICE_CONTROL

DeviceIoControl

To this day we don't know the exact purpose of the various audited IOCTL-s in the driver. Many of them seem to be implementing wrappers around different system calls, most likely to enforce some kind of filtering or additional access control. The rest of the IOCTLs appear to be related to interacting with settings and configuration files.

Bug Discovery

During a normal audit we would spend time to understand the attack surface, reverse engineer the implementation and either follow the user provided data or look for deep bugs in how certain systems interact. On these time-constrained engagements we have to be more opportunistic as we can't afford a thorough, systematic approach. Instead, we aim to quickly identify where user data is handled and verify the parsing logic that follows the data access.

This type of approach was used for auditing the

aswSnx

The

ProbeForRead/ProbeForWrite

With this method we quickly identified an IOCTL that checks the validity of user pointers with the

ProbeForRead

0x82AC0204

As can be seen in the following code, while trying to capture the string supplied by the user, the Length field of the

_UNICODE_STRING

The pseudocode of the vulnerable function is presented below:

1
__int64 sub_14005E99C(char a1, __int64 a2, const WCHAR *a3, __int64 a4, ...)
2
{
3
[...]
4
  if ( !a1 && unicodestring_user )
5
  {
6
    ProbeForRead(unicodestring_user, 0x10, 1u); // [0]
7
    ProbeForRead(unicodestring_user->Buffer, unicodestring_user->Length, 1u); // [1]
8
  }
9
  v17 = sub_140071C6C((__int64)v18, &v14[v23 + 13], unicodestring_user); // [2]
10
}
11

12
__int64 __fastcall sub_140071C6C(__int64 a1, _QWORD *a2, _UNICODE_STRING *unicodestring_user)
13
{
14
  PoolWithTag = ExAllocatePoolWithTag(PagedPool, unicodestring_user->Length + 16, 0x20786E53u); // [3]
15

16
  if ( !PoolWithTag )
17
    return 0xC000009A;
18

19
  Length = unicodestring_user->Length;
20
  *PoolWithTag = unicodestring_user->Length;
21
  PoolWithTag[1] = Length;
22
  *((_QWORD *)PoolWithTag + 1) = PoolWithTag + 8;
23
  Buffer = (char *)unicodestring_user->Buffer;
24
  if ( Buffer )
25
  {
26
    if ( a3->Length )
27
      private_memmove((_OWORD *)PoolWithTag + 1, Buffer, unicodestring_user->Length); // [4]
28
  }
29
  *a2 = PoolWithTag;
30
  return 0;
31
}

During the execution of the

sub_14005E99C

ProbeForRead

_UNICODE_STRING

sub_140071C6C

• First at [3] when the kernel buffer is allocated

• Second at [4] when the user memory is copied to the freshly allocated kernel buffer

The problem with this sequence of events is that the kernel assumes that the length values remain the same between [3] and [4], however the system does not provide such guarantees. A malicious user-process can change the length field between the two accesses resulting in a different kernel allocation and copy size. If the allocation size is chosen to be smaller than the copy size that would lead to a kernel heap pool overflow where user supplied data is copied beyond the boundaries of the allocated kernel buffer. Please note that this is a very strong and convenient primitive as both the initial pool size, the overflow amount and the overflow data is controlled by the user.

The complete input of the vulnerable IOCTL and the definition of the

_UNICODE_STRING

1
typedef struct _UNICODE_STRING {
2
  USHORT Length;
3
  USHORT MaximumLength;
4
  DWORD Padding;
5
  PWSTR Buffer;
6
} _UNICODE_STRING;
7

8
typedef struct _InputSubStruct {
9
  wchar* pString;
10
  DWORD Type;
11
  char unknown[0x4];
12
  void* pData; // wchar* or UNICODE_STRING*
13
} InputSubStruct;
14

15
typedef struct _InputStruct {
16
  char unknown[0x88];
17
  InputSubStruct SubStructArray[0xF];
18
  char unknown2[0x8];
19
} InputStruct;

Once a vulnerability is identified through static analysis the natural next step is to dynamically reproduce it. To our surprise our initial attempts to exercise the vulnerable code were an absolute failure. When we called the target IOCTL with seemingly right parameters, nothing happened, no crash, no side effects. Taking a closer look with a debugger showed that the code was not even executing.

Investigation on this issue was pointing to the sandbox configuration, the process initiating the IOCTL needs to be registered into the avast sandbox to access it, this means that a standard process can not access it by default.

Enter Sandbox

Further investigation and reversing revealed that the

aswSnx

The

aswSnx

%ProgramData%\Avast Software\Avast\snx_lconfig.xml

By default the configuration file is empty and therefore nothing is executed within the sandbox. Further understanding the

aswSnx

fAutosandbox

scanhandle

An example configuration that allows access to the vulnerable attack surface:

1
<?xml version="1.0" encoding="UTF-16"?>
2
 <SnxConfig type="Configuration" version="3">
3
  <Kernel>
4
    <Avast>
5
      <ProcessNameEntry flags="fLastFilenamePart|fAutosandbox" scanhandle="1" name="exploit.exe"/>
6
    </Avast>
7
    [...]
8
  </Kernel>
9
</SnxConfig>

Modifying the configuration by hand through disabling its protection with a kernel debugger is sufficient to confirm our understanding of the driver, however it is not practical for reaching and exploiting the vulnerability. We had to go back to do some further reversing to search for APIs or some indirect behaviors that would allow the modification of the config file to spawn our process in the sandbox.

Most of the IOCTLs that are related to the configuration file are not reachable directly from an average user process. As they require the driver to be opened with write permission, however the driver itself prevents regular processes opening it for writing. Most likely the reason is to prevent unprivileged processes from removing entries from the sandbox profile. Fortunately, the IOCTL that is used to register new processes to the sandbox config and set their initial configuration is accessible with read only permissions.

The IOCTL that allow us to do this is

0x82AC0054

1
typedef struct _CfgInput {
2
  UINT64 Flags;
3
  UINT64 ScanHandle;
4
  UINT64 EngineFlags;
5
  wchar_t Name[0x805];
6
} CfgInput;

The

ScanHandle

Flags

Name

Additional Findings

As the attack surface is relatively obscure and the initial vulnerability was a quite shallow find we decided to spend a bit more time auditing the same area. Within the same IOCTL handler we found multiple variants and similar bugs, they process similar inputs with different string encodings The findings are briefly introduced below.

Another Double Fetch into a Pool Overflow

Similar to the originally introduced double fetch vulnerability when the same IOCTL processes the

pString

In both loops the length of the string is determined by the location of the first null byte. As the string resides in user space its content, and consequently its size, can change between [0] and [3]. If the length is larger during the second iteration the pool buffer is overflown with user controlled data.

The pseudocode is presented below:

1
typedef struct _InputSubStruct {
2
  wchar* pString;
3
  DWORD Type;
4
  char unknown[0x4];
5
  void* pData; // wchar* or UNICODE_STRING*
6
} InputSubStruct;
7

8
typedef struct _InputStruct {
9
  char unknown[0x88];
10
  InputSubStruct SubStructArray[0xF];
11
  char unknown2[0x8];
12
} InputStruct;
13

14
__int64 sub_14005E99C(char a1, __int64 a2, const WCHAR *a3, __int64 a4, ...) {
15
[...]
16
  // [0] Calculate size of the string
17
  size = -1;
18

19
  do {
20
    ++size;
21
  }
22

23
  while (pString[size]);
24

25
  // [1] Buffer allocation based on the calculated size
26
  heap_buff_p = ExAllocatePoolWithTag(PagedPool, 2 * size + 2, 0x20786E53u);
27
[...]
28

29
  // [3] Copy the string into the allocated buffer while fetching a second time the string
30
  do {
31
    v25 = *pString;
32
    *heap_buff_p = *pString;
33
    pString++;
34
    ++heap_buff_p;
35
  }
36
  while ( v25 );
37
[...]

Another problem with this code is that the supplied user pointer is inherently trusted. It is dereferenced directly without being verified by the appropriate

ProbeForRead

Pool Buffer Overflow During Process Termination

The same IOCTL can be used to provide a wide char string to the kernel. The exact purpose of this string is not clear, however, the kernel allocates a new buffer and stores the user provided string. Both the size and the content is controlled by the user. The string is saved for later processing in an internal structure.

When the sandboxed process is terminated it is unregistered from the sandbox. The deregistration process involves a step when the previously captured and saved, user-provided string is copied into a fixed-size kernel heap pool buffer. The root cause of the vulnerability is the misuse of the

*snprintf

The pseudocode associated with the bug is the following:

1
__int64 __fastcall sub_14005A7DC(__int64 a1, __int64 a2) {
2
  [...]
3
  _wsnprintf(allocation_0x420, pString_copy_size >> 1, L"%ws", pString_copy);
4
  [...]
5
}

The code responsible for capturing the user provided

pString

Yet Another Double Fetch into a Pool Overflow

In the same IOCTL, there is yet another double fetch issue while processing the

pData

InputSubStruct

memcpy

As previously the length and content of the user string can be altered between [0] and [3] which results in different sizes being used for the allocation and the copy.

The pseudocode associated with the bug is the following:

1
typedef struct _InputSubStruct {
2
  wchar* pString;
3
  DWORD Type;
4
  char unknown[0x4];
5
  void* pData; // wchar* or UNICODE_STRING*
6
} InputSubStruct;
7

8
typedef struct _InputStruct {
9
  char unknown[0x88];
10
  InputSubStruct SubStructArray[0xF];
11
  char unknown2[0x8];
12
} InputStruct;
13

14
__int64 sub_14005E99C(char a1, __int64 a2, const WCHAR *a3, __int64 a4, ...) {
15
  [...]
16

17
  ProbeForRead((volatile void *)pData, 2ui64, 1u);
18

19
  // [0] Calculate allocation size
20
  if ( pData ) {
21
    i = -1i64;
22
    do
23
    ++i;
24
    while (pData[i]);
25
    allocation_size = 2 * i;
26
  }
27

28
  else {
29
    allocation_size = 0;
30
  }
31

32
  v38 = &v14[v23];
33
  // [1] Kernel heap buffer allocation
34
  v17 = alloc_buffer(1i64, &v38->dst_struct, allocation_size);
35
  if ( v17 < 0 )
36
  goto LABEL_102;
37
  // [2] Calculate copy size
38
  if ( pData ) {
39
    j = -1i64;
40
    do
41
    ++j;
42
    while (pData[j]);
43
    // Copy size assignment
44
    v38->dst_struct->length = 2 * j;
45
    [...]
46
     // [3] memcpy using the recalculated size
47
     memcpy(v38->dst_struct->data, (char *)pData, v38->dst_struct->length);
48
    [...]
49
  }
50
}

Patches

We have done a very brief patch analysis to verify if the vulnerabilities were correctly fixed before publishing. The first double fetch vulnerability is fixed by copying the unicode description structure into the kernel before processing. This prevents further access to a malicious user-space process, eliminating the vulnerability.

The other double fetch vulnerabilities are addressed by removing the second loop that recalculates the length of the string. Instead the result of the original iteration is used to make the allocation and the copy.

The pool overflow on process termination has been fixed by verifying the size of the user supplied string against the fixed allocation size before the copy.

Finally, new validity checks have been added before user addresses are accessed and dereferenced in the kernel driver.

Conclusion

We spent around a month on this project and during that time we found four distinct kernel heap overflow vulnerabilities and two system dos vulnerabilities in a widely deployed target and we successfully exploited them for system privilege escalation. Reaching the vulnerabilities required to solve some unique challenges that were raised by the sandboxing model of the target application. After further investigation and understanding the sandbox we found a way to modify its configuration, spawn a controlled process within it and reach and exploit the vulnerable attack surface. This work proves that it is still possible to find high impact vulnerabilities in established, widely used software with limited resources, relying on manual code auditing, using opportunistic heuristics.

The next part of this blog post series will contain all the exploitation details.

Timeline

• 25-03-14: Vulnerability reports submitted to Bugcrowd platform (as per vendor instructions)

• 25-03-18: All submissions (except one of the DoS) are marked as a duplicate of each other by the vendor

• 25-03-27: Further explanation and evidence is provided that the submissions are variants and not duplicates

• 25-04-01: Updated version of Avast is released fixing all but one of the heap overflow vulnerabilities

• 25-05-26: Vendor informs us of the patched version

• 25-05-28: Bounty is awarded for the submission

• 25-06-05: Patches are confirmed and vendor is alerted of the one remaining vulnerability

• 25-06-11: Due to the vendor request further technical details are provided

• 25-08-29: A status update is requested by us

• 25-10-02: Vendor confirms that they can no longer reproduce the vulnerability

• 25-10-03: We confirm that the last vulnerability has been fixed

• 25-11-11: CVE-2025-13032 is assigned and published

We would like to thank the Avast and Bugcrowd security team for coordinating with us in the disclosure process and fixing the vulnerabilities.

It is our opinion that eagerly classifying vulnerability variants as duplicates is not a pragmatic approach as it could dissuade researchers from reporting multiple vulnerabilities at the same time and miss-classifications can extend the patching time.

We also applaud the Avast security team for their incredibly fast patch response, it took 12 days from initial acceptance to release a fixed version of the product which is above and beyond industry standard patch cycle times.

Additional Notes

The pseudocode references are taken from

Avast 25.2.9898.0
